8.7 cu. ft. capacity KBWF 240 Plant Growth Chamber with light and humidification includes illumination cassettes and stainless steel racks | 1410-12 displayed...

8.7 cu. ft. capacity KBWF 240 Plant Growth Chamber with light and humidification includes illumination cassettes and stainless steel racks | 1410-12 displayed

Environmental Test Chambers

KBWF Growth Chambers by BINDER Worldwide

Manufactured By: Binder

Need Help?

(714) 578-6100

Mon - Fri, 5:30 AM - 5:30 PM, PST

Email Chat

Want a quote quickly ?

Submit a QuickQuote request

Select Product

Voltage All 120 V 240 V Sort Order: Descending Ascending	Type All Growth Sort Order: Descending Ascending	Design All Free Standing Sort Order: Descending Ascending	Application All Plant Growth Sort Order: Descending Ascending	Exterior Material All Powder Coated Steel Sort Order: Descending Ascending	Capacity All 8.7 cu. ft. 24.7 cu. ft. Sort Order: Descending Ascending	Temperature Range All Ambient to 70°C Sort Order: Descending Ascending	Interior Material All Stainless Steel Sort Order: Descending Ascending	Model All KBWF Sort Order: Descending Ascending	Manufacturer SKU All 9020-0336 9020-0337 Sort Order: Descending Ascending	Capacity Range All <12 cubic feet >24 cubic feet Sort Order: Descending Ascending	Terra Part #	Price	Ships in
120 V	Growth	Free Standing	Plant Growth	Powder Coated Steel	24.7 cu. ft.	Ambient to 70°C	Stainless Steel	KBWF	9020-0337	>24 cubic feet	1410-13 70465	$27,004	20-26 Days	2
240 V	Growth	Free Standing	Plant Growth	Powder Coated Steel	8.7 cu. ft.	Ambient to 70°C	Stainless Steel	KBWF	9020-0336	<12 cubic feet	1410-12 70464	$22,501	20-26 Days	3

Voltage

Type

Design

Application

Exterior Material

Capacity

Temperature Range

Interior Material

Model

Manufacturer SKU

Capacity Range

Some ship in:

Usually Ships in:

CHOOSE ACCESSORIES & BUY OR QUOTE

Qty

Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.

Qty

Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.

See Product Details

Back to product group

Select a product line for product summary

Top
Select Product Buy
Details Details
Photos & Videos Gallery
Features & Benefits Features
Accessories Accessories
Similar Similar
Manuals & Resources Resources

Top
Select Product Buy
Details Details
Photos & Videos Gallery
Features & Benefits Features
Accessories Accessories
Similar Similar
Manuals & Resources Resources

Product Details

Features & Benefits

Products similar to this one

Buy Accessories

Manuals & Resources

Product Details

KBWF Series Growth Chambers provide humidity and homogeneous light distribution with natural illumination via a patented lighting system
Ideal for growing Arabidopsis, an extensively studied plant organism and other organisms dependent on well-defined light cycle and tightly controlled temperature
Models meet the strict demands of scientific, pharmaceutical and industrial fields by providing an accurate simulation of biological, chemical and physical conditions
Patented lighting system ensures homogenous light distribution
Flexible positioning of illumination cassettes with three different, individually selectable light spectra
APT.line preheating chamber technology with adjustable fan speed
Includes illumination cassettes and stainless steel racks
Industry use: Pharmaceutical, scientific, industrial and chemical
Integrated weekly program in real-time, heated door and access port with silicone plug, 30 mm
Humidity regulation with capacitive humidity sensor and vapor humidification
Inner door (tightly sealed) made of tempered safely glass (ESG safety glass with special TIMELESS coating)
Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
Intuitive touchscreen controller with time-segment and real-time programming with internal data recording
LCD monitor and controller with interval programming

Environmental Test Chambers

Features & Benefits

Features and Benefits

Homogeneous Temperature Distribution

APT.line™ preheating chamber technology with dual-side air flow ensures long-term temperature uniformity even with a full load

KBWF Growth Chamber Humidity Control

Patented long-life humidification system and capacitive humidity sensor ensure on target humidity values.

KBWF Growth Chamber Intuitive Touchscreen Controller

KBWF Growth Chambers feature state-of-the-art controller technology with time-segment, real-time programming and internal data recording.

Other products you may find relevant

Buy Accessories

Manuals & Resources

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Model	KBWF 240	KBWF 720
Electrical	200-240v, 50Hz	200-240v, 50Hz
Net weight of the unit (kg)	430 lbs. (195kg)	825 lbs. (374kg)
External Dimensions W" x D" x H" (mm)	36.4 x 31.5 x 57.7 in. (925 x 800 x 1465 mm)	49.2 x 35 x 75.8 in. (1250 x 890 x 1925 mm)
Internal Dimensions W" x D" x H" (mm)	25.6 x 19.1 x 30.9 in. (650 x 485 x 785mm)	38.3 x 22.7 x 49.2 in. (973 x 576 x 1250mm)
Internal Volume (L)	8.72 cu. ft. (247 L)	24.7 cu. ft. (700 L)
Unit doors	1	2
Number of stainless steel racks (std./max.)	2/7	3/12
Number of illumination cassettes (std./max.)	2/2	3/3
Temperature range without illumination cassettes [°C]	32-158 °F (0-70 °C)	32-158 °F (0-70 °C)
Temperature range with 100% illumination [°C]	50-140 °F (10-60 °C)	50-140 °F (10-60 °C)
Temperature variation without illumination cassettes [± K]	0.5	0.5
Temperature variation with 100% illumination [± K]	0.5	1
Temperature fluctuation without illumination cassettes [± K]	0.1	0.1
Temperature fluctuation with 100% illumination [± K]	0.2	0.1
Humidity range without illumination [% RH]	10-80	10-80
Humidity range with illumination cassettes, with illumination [% RH]	10-75	10-75
Illumination per cassette Daylight tubes [lx]	9000	13000
Illumination per cassette Fluora® growth lamps [lx]	7500	10500
Illumination per cassette Arabidopsis lamps [lx]	11000	14000
Computer Interface	Ethernet	Ethernet

Model

KBWF 240

KBWF 720

Electrical

200-240v, 50Hz

Net weight of the unit (kg)

430 lbs. (195kg)

825 lbs. (374kg)

External Dimensions W" x D" x H" (mm)

36.4 x 31.5 x 57.7 in.
(925 x 800 x 1465 mm)

49.2 x 35 x 75.8 in.
(1250 x 890 x 1925 mm)

Internal Dimensions W" x D" x H" (mm)

25.6 x 19.1 x 30.9 in.
(650 x 485 x 785mm)

38.3 x 22.7 x 49.2 in.
(973 x 576 x 1250mm)

Internal Volume (L)

8.72 cu. ft. (247 L)

24.7 cu. ft. (700 L)

Unit doors

Number of stainless steel racks (std./max.)

2/7

3/12

Number of illumination cassettes (std./max.)

2/2

3/3

Temperature range without illumination cassettes [°C]

32-158 °F (0-70 °C)

Temperature range with 100% illumination [°C]

50-140 °F (10-60 °C)

Temperature variation without illumination cassettes [± K]

0.5

Temperature variation with 100% illumination [± K]

0.5

Temperature fluctuation without illumination cassettes [± K]

0.1

Temperature fluctuation with 100% illumination [± K]

0.2

0.1

Humidity range without illumination [% RH]

10-80

Humidity range with illumination cassettes, with illumination [% RH]

10-75

Illumination per cassette Daylight tubes [lx]

9000

13000

Illumination per cassette Fluora® growth lamps [lx]

7500

10500

Illumination per cassette Arabidopsis lamps [lx]

11000

14000

Computer Interface

Ethernet
