- Available ISO Ratings: ISO 6, ISO 7, ISO 8
- Ergonomic electric adjustable height cleanroom table easily changes height with the push of a button
- Front key pad stores up to 4 heights and displays exact desk height for hassle free adjustment
- Quickly change positions throughout the workday for improved health and productivity
- Sealed design guards against contamination and meet ISO 6 (Class 1,000) particle standards
- Heavy duty legs support up to 880 lbs uniform distributed load; safely adjust height without moving equipment off table
3504-PP-01
3504-PP-01 72067
ErgoHeight™ Electric Height Adjustable Cleanroom Workstations
Read more
Manufactured By: Terra Universal
Print
Want a quote quickly ?
Submit a QuickQuote requestProduct Details
Product Details
ErgoHeight™ Adjustable Work Stations
Watch Terra's ErgoHeight™ Workstations Video- ErgoHeight™ Auto Adjustable Cleanroom Work Station
- of 2Start Over
EroHeight™ workstations are ideal for boosting productivity and comfort. Watch Terra's ErgoHeight™ Workstations Video EroHeight™ work stations provide automatic adjustable height for user comfort. Robust moterized lifters provide industry leading speed and durability.
Features & Benefits
Features and Benefits
ErgoHeight™ Automatic Adjustable Work Station
ErgoHeight™ tables provide a 15" range of vertical motion to ensure personnel comfort without disrupting tabletop set-ups; all-stainless steel construction and sealed lifting mechanism for cleanroom use
ErgoHeight™ Intuitive Controls
ErgoHeight™ compact control panel includes four buttons for user height presets and a digital display
ErgoHeight™ Reinforced Frame
The reinforced steel frame of the ErgoHeight™ adjustable-height table enhances lateral stability, ensuring a stable work surface ideal for microscopy and high-precision benchtop equipment.
BioSafe®: Terra's Ultimate Cleanliness Rating
Terra's BioSafe products are designed for the most critical applications: no gaps and crevices where microbes colonize, rounded corners for easy disinfection, won't produce contaminants during sterilization, and exceeds cGMP, IEST, ASTM and ISO 14644-1 requirements.
OpenTop Perforated Top
Hidden reinforcements minimize dead spots, add strength, and eliminate deflection without dead spaces whereas conventional perforated tops rely on “blank out” support panels, which create turbulence in cleanroom laminar flow.
Bull-Nose Rounded Edge Comparison
Terra's one-piece bull-nose rounded edges increase operator comfort and reduce particulate shedding caused by sharp or abrasive edges. The smooth, continuous-seam welds also eliminate cracks and crevices that can harbor contaminants.
Vibration-Isolated Configurations for Improved Stability
ErgoHeight™ workstations can be configured with vibration dampening tabletops. The pneumatic vibration-free mounts isolate up to 90% of building vibration to improve stability for vibration sensitive operations and minimize worker fatigue and nausea during high-magnification work.
Durable, High-Quality Glides
Product glides and leveling feet represent the first line of defense against cleanroom contamination. As glides come into contact with cleaners and harsh chemicals, they are often the first component to deteriorate. Terra's glides are durable, chemical resistant, built-to-last, and ISO-rated.
Benchtop ISO 5 Vertical Laminar Flow Hood with Automatic Height Adjusting Table
Vertical laminar flow hoods provide a HEPA-filtered work area for protection from particle contaminants. Benchtop laminar flow hoods can easily mount to an automatic height adjusting table (28”-43”H). Perfect for workstations with heavy or fragile equipment.
UL-Tested Cleanroom Workbenches for Highest Quality and Safety
Ensuring the safety of your personnel and equipment is essential. UL is recognized around the world as the leader in product safety testing and certification. Terra’s stainless steel cleanroom workbenches are tested by UL to meet the strictest safety and stability standards.
Stainless Steel ISO 6 Glovebox on Automatic Height Adjusting Table with N2 Generator
Gloveboxes can easily mount to an automatic height adjusting table (28”-43”H). Ideal for workstations with sensitive equipment that undergo frequent height adjustment. A compact Nitrogen generator requires only a compressed air supply for continued nitrogen gas supply.
Continuous Product Improvement
At Terra, we strive to develop and produce the highest quality products for our customers to improve health, safety, performance, and yields. Our product quality is enabled by high-grade manufacturing equipment and processes, 45 years of engineering and application expertise, and our commitment to continuously improve.
ISO 5 Vertical Laminar Flow Clean Bench with Automatic Height Adjusting Table
Automatic height adjusting tables fit perfectly inside free-standing laminar flow clean benches. The separate workstation helps isolate vibration from the fans mounted above the hood. Dual motor electric height adjusting columns beneath the table allow users to quickly raise or lower the work surface without moving equipment off the table.
Products Compliant With Your ISO Rating
Provide Terra with your desired ISO rating. We will tailor the product to meet your rating and supply a certificate of compliance appended to your invoice, to be included in your compliance package. All certificates are archived in Terra's system for quick retrieval.
Other products you may find relevant
-
Usually Ships in 4 - 6 days -
Some ship in 8 - 14 days -
Group of 16 productsElite and Eton ISO 5 Ergonomic Cleanroom/ESD Chairs by BioFit FromAs low as $598Some ship in 5 - 7 days -
Some ship in 5 - 7 days -
Some ship in 1 - 3 days -
Some ship in 3 - 5 days -
Some ship in 5 - 7 days -
Group of 18 productsElite and Eton Series Ergonomic Laboratory Chairs by BioFit FromAs low as $401Some ship in 5 - 7 days -
Some ship in 8 - 14 days -
Some ship in 3 - 5 days -
Some ship in 1 - 3 days -
Some ship in 8 - 14 days -
Some ship in 1 - 3 days -
Some ship in 21 - 23 days -
Some ship in 10 - 16 days -
Some ship in 5 - 7 days -
Some ship in 20 - 25 days -
Some ship in 4 - 6 days
Page 1 of 5
Buy Accessories
Manuals & Resources
ErgoHeight™ Electric Height Adjustable Cleanroom Workstations
- Robust motorized lifters automatically raise, lower and level the work surface for optimal operator comfort and convenience while ensuring lateral stability
- Ergonomic electric adjustable height cleanroom table easily changes height with the push of a button
- Ergonomic benchtop positioning eliminates back stress—and costly lawsuits!
- Front keypad stores up to 4 heights and displays exact desk height for hassle free adjustment
- Quickly change positions throughout the workday for improved health and productivity
- Sealed design isolates motor to guard against contamination and meet ISO 5 (Class 100) particle standards
- Heavy duty legs support up to 880 lbs; safely adjust height without moving equipment off table
- Ideal for work with high-profile processing equipment
- Height-adjustable from 28" to 43"
Sure, Your Bench is Adjustable—But Do You Adjust It?
Adjustability means nothing if it's inconvenient or unfeasible.
True, many benches feature telescopic legs, but how likely is an operator to perform a manual adjustment if it means temporarily relocating heavy, expensive process equipment? How many helping hands are required? How long will it disrupt critical process operations? And how long will it be before someone else wants the bench just the way it was?
Adjustable cleanroom chairs help solve these problems, but in many cleanroom applications, a chair just isn't enough. Many test and assembly procedures require adjustment outside the range of most adjustable chairs, forcing an operator to hunch their back to meet the occasion. Other processes require an operator to stand or move from one position to another, so chairs of any kind aren't much help. When frequent adjustment entails moving heavy, expensive equipment, the temptation is to let someone suffer—and risk a back injury, lost productivity, even lawsuits.
Note: Because the ErgoHeight™ Work Bench requires a steady benchtop for safe operation, it is not recommended for use with an over-head light fixture.
Smooth Operation
The ErgoHeight™ adjustable height cleanroom table incorporates a high-torque, low RPM motor inside two lifters located on the right and left sides of the table. Each lifter can safely handle 440 pounds (199.6 kg) of net load, for a total net load of 880 pounds (399.2 kg). Lifting speed is 0.5"/second.
A control panel and keypad mounted on the front of the benchtop frame contains all necessary switches for up/down table motion and to level the work surface. This option is ideal for use with process equipment that requires height adjustment to suit individual operators, as well as for leveling the system or interfacing it with adjacent operations. Program up to four pre-set positions.
Standard ErgoHeight™ electric adjustable height workbenches are height-adjustable from 28" to 43", floor to work surface. Vibration-free height range is 30.375" to 51.375" floor-to-top.
Cleanroom Compatible Design
BioSafe® electric automatic standing workstations are designed for use in a cleanroom environment. The table top features a rigid solid-welded 304 stainless steel construction, suitable for environments with strict cleaning protocol. The thermally protected lifters are completely sealed inside the legs to ensure particle retention and cleanroom compatibility. And because an ErgoHeight™ Work Station provides smooth, controlled height adjustment under virtually any load, it allows automatic height adjustment of vibration-sensitive equipment. Typically you can bring delicate test equipment, even liquids, to the optimal level without lengthy disruption, thereby making the most of expensive cleanroom time. For enhanced vibration isolation in microscope operations, select Terra's Vibration-Free ErgoHeight™ Station.
The ErgoHeight™ electric height adjustable cleanroom table is available with a variety of bench tops to suit your particular application requirement. Non-BioSafe automatic adjustable height workstations offer a lower cost alternative with powder-coated steel base for less stringent cleanliness requirements. Perforated tops feature 0.25"-diameter perforations with an open area of 40% to ensure proper vertical laminar airflow.
