Select Product
Voltage

Oil-less

Ultimate Pressure

Maximum Pumping Speed

ISO Class

Terra Part #PriceShips in
115 V Yes 2 mbar 65 L/min ISO 8 7906-08A 73520 $4,7495-7 Days2
Ships Free Free shipping in contiguous USA In stock
115 V Yes 8 mbar 97 L/min ISO 8 7906-29 52613 $3,6815-7 Days3
Ships Free Free shipping in contiguous USA In stock
115 V Yes 10 mbar 65 L/min ISO 8 7906-50 52667 $1,3625-7 Days4
Ships Free Free shipping in contiguous USA In stock
115 V Yes 12 mbar 25 L/min ISO 8 7906-51 52668 $2,5595-7 Days5
Ships Free Free shipping in contiguous USA In stock
115 V Yes 12 mbar 35 L/min ISO 8 7906-06A 73516 $2,9765-7 Days6
Ships Free Free shipping in contiguous USA In stock
115 V Yes 53 mbar 35 L/min ISO 8 7906-03A 73373 $1,8095-7 Days7
Ships Free Free shipping in contiguous USA In stock
115 V Yes 200 mbar 31 L/min ISO 8 7902-00 19892 $6705-9 Days8
Ships Free Free shipping in contiguous USA
120 V Yes 8 mbar 173 L/min ISO 8 7906-26A 73527 $5,2175-7 Days9
Ships Free Free shipping in contiguous USA In stock
120 V Yes 100 mbar 36 L/min ISO 8 7906-07A 73377 $4,5815-7 Days10
Ships Free Free shipping in contiguous USA In stock
120 V Yes 4200 mbar 31 L/min ISO 8 7903-00 19896 $83515-17 Days11
Ships Free Free shipping in contiguous USA Only 1 left in stock
230 V Yes 2 mbar 65 L/min ISO 8 7906-08A-220 73521 $4,7615-7 Days12
Ships Free Free shipping in contiguous USA In stock
230 V Yes 12 mbar 21/25 L/min ISO 8 7906-51-220 73515 $2,5595-7 Days13
Ships Free Free shipping in contiguous USA In stock
230 V Yes 12 mbar 57 L/min ISO 8 7906-50-220 73524 $1,3625-7 Days14
Ships Free Free shipping in contiguous USA In stock
230 V Yes 100 mbar 33 L/min ISO 8 7906-07A-220 73518 $4,3225-7 Days15
Ships Free Free shipping in contiguous USA In stock
240 V Yes 200 mbar 31 L/min 7902-01 19894 $36815-17 Days16
Ships Free Free shipping in contiguous USA Only 5 left in stock
220 V Yes 0.004 mbar 31 L/min ISO 8 7903-01-220 19898 $8971-3 Days17
Ships Free Free shipping in contiguous USA Quick Ship+ Only 3 left in stock
240 V Yes 53 mbar 29/35 L/min ISO 8 7906-03A-220 73514 $1,8095-7 Days18
Ships Free Free shipping in contiguous USA In stock
240 V Yes 12 mbar 29/35 L/min ISO 8 7906-06A-220 73517 $2,9765-7 Days19
Ships Free Free shipping in contiguous USA In stock
Voltage
Oil-less
Ultimate Pressure
Maximum Pumping Speed
ISO Class
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Select a product line for product summary
Product Details
Product Details
  • •  Available ISO Ratings: ISO 8
  • Oil-free, diaphragm pumps for rough and medium-high vacuum; ideal for research and science applications
  • An economically and ecologically superior alternative to water-operated vacuum pumps
  • Also used as regeneration pumps in combination pumping systems
  • ILMVAC diaphragm pumps are quiet and compact with low vibration
  • Chemically resistant diaphragm pump models MPC are used with aggressive solvents and acid vapors
  • Made from cleanroom-compatible aluminum, PTFE, PP and PVDF
  • Maintenance and service work is fast and easy
  • ILMVAC guarantees outstanding operation and long vacuum pump life span; rated for thousands of hours
  • Manufactured and tested in accordance with DIN 28 432
  • Applications include vacuum distillation, vacuum concentration, molecular distillation, drying ovens, vacuum filtration, and gel drying
  • Pumping and connection heads are carbon fiber reinforced with virtually no electrical conductivity
